Technology

Physis Plus Physical Modelling

Manuals

3

Total Stop Controls

46 Organ Stops + 4 Orchestral Voices

Pedal

9

MAN I

11

MAN II

12

MAN III

14

Alternative Organ Voices

5 for each tab

Alternative Orchestral Voices

More than 30 overall

Couplers

6

Memory Locations

1000 (000 - 999)

Piston Sequencer

Two thumb pistons

Pipe Sets

Baroque, Romantic, Symphonic

Height (excluding music desk)

cm 31.3 - 12.32"

Height (including music desk)

cm 52.3 - 20.59"

Width

cm 90 - 35.43"

Depth (excluding pedal board)

cm 62 - 24.4"

Weight

32 kg - 70.54 Lbs

Stop Controls

Tilt Tabs

Laminated Wood

Light oak

Organ Stops

46

Pedal

9

Manual I

11

Manual II

12

Manual III

14

Couplers

6

Tremulants

3, Programmable with independent Depth and Speed for each Organ Division

Orchestral Voices Stops

4

Styles

3 Preset: Baroque, Romantic, Symphonic

Temperaments

19

Ensemble

Adjustable

Optionals

Transport Bag
Bench
Standard Stand
Large Stand
MIDI pedalboard
Expression Pedals (2 unit for Midi Pedalboard)
Volume Pedal
Sustain Pedal

Display Dimensions

128 x 64 Graphic with Backlight

Stops Voicing

Available

Divisional Volume

Available

Tremulant

3 independent for each division

Reverb

8 presets

Ensemble Effect

Adjustable

Temperaments

19 Historical + 4 user programmable

Short Octave

Available

Keyboards Inversion

Available

Internal Routing

Programmable for each stop

Internal Equalizer

5 Band Graphic EQ

MIDI Sequencer

Available

File Manager

Load, Save, Backup, Restore

Wooden Desk

Metal and Laminated

Standard Keyboards

Available

Plastic Black Keyboard Covered with Real Wood

Optional

Ivory / Wood Colored Plastic With Wooden Core

32 note Straight Concave or Flat, Radiating Concave

Optional

30 note Straight Concave or Flat, Radiating Concave

Option

MIDI In - MIDI Out

Available

Aux In, Aux Out

Available

Headphones Out

Available

USB

A-Type (USB pen) B-Type (Connection to Physis Editor)

Expression Pedal In

Available

Crescendo Pedal In

Available

Sustain Pedal In

Available

Channels

4 programmable

Channel Assign

Voice, General, Reverb

Equalizer

5 Band Graphic EQ for each channel

Routing

Programmable for each stop

Volume

Adjustable for each channel

True Stereo Reverb

8 new unique presets

Additional Parameters

Dry/Wet
Early reflections
Decay Time

Left/Right

Assignable to external outpu

Internal Amplifiers

2 channels Class-D amplifier 2x55 W

Internal Speakers

2 tweeter | 2x6” woofer

Pipe Set

Pipe sets management

Tuning

Instrument’s tuning parameters

Combinations

Management of the Combinations sets

Voicing

Alternative voices and sound generations parameters

Setup

Instrument general settings

MIDI

MIDI settings

Backup / Restore

Save / Load configurations / Factory Reset

Transposer

-6/+5 semitones

Automatic Pedal

Yes

Enclosed

Yes

Reverb

8 different venues emulator

Internal Amp EQ

5 bands digital Graphic EQ

MIDI Sequencer

Interactive sequencer with Overdubbing function

Keyboard Inversion

Yes

Organ Setup lock

With Password

ON/OFF switch

Switch

Line Outputs

4

Output Volume Control

Adjustable, for each output

Voices Output Routing

Programmabile, for each section

Output EQ

5 bands digital Graphic EQ for each output

MIDI Interface

In, Out

Stereo Headphone Output

Si

Stereo Aux Input

yes

USB for Pen Drive

Yes

Cabinet

Black painted metal with light oak simulated wood sides

Music Rack

Metal

Dimensions (WxHxD)

cm 90 x 31.3 x 62 cm - 35,43 " x 13.32" x 24.4"

Weight

Kg 32 / Lbs 70.34
