User Manual Danhild VARIO - Version 1

3 INSTALLATION

3.1 Installation and connection

3.1.1 Installation of instrument

1. Position the instrument on a stable, horizontal surface.

2. Install the included music stand, see 3.1.2.

3. Install the pedal keyboard, see 3.1.3.

4. Place the organ bench (C), (see page 5), over the pedal keyboard (E).

5. Connect the cord/plug from the bench to the power socket (F) in the VARIO organ.

6. Make sure the voltage of the instrument matches the voltage of the mains. See the serial label (I).

7. Connect the instrument to an earthed power socket.

3.1.2 Installation note stand

The included music stand (A) is placed in the slot (G) above the keyboards.

Be aware that the music stand can be placed only in one way downwards.

3.1.3 Installation pedal board

Install the pedal keyboard (E), by pushing the pedal board against the black pedal front cover (H).

The surface on which the pedal board is positioned must be stable and horizontal and in the

same level as the surface on which the instrument is positioned.

A

G

E

H

F

I
