User Manual Danhild VARIO - Version 1

4.9.9 Datadump

The Datadump function sends settings from the VARIO to a storage medium

(a sequencer, for example) through the MIDI SEQ output. See § 3.9 (External Connections).

The settings to send are: the content of all capture memory locations and all settings which can be

set via the Danhild VARIO Menu, except Key Volumes. Key Volume settings are a part of the intonation data.

1. Press the MENU button.

2. Use the - and + buttons to select the

Datadump function on the display.

3. Press the ENTER button. The

Press ENTER

text appears on the display.

4. Make sure your storage medium is connected.

5. Press the ENTER button. When data is being sent,

Sending data...

Appears on the display.

Sending data will take some time.

6. If the data dump is complete, the main

menu appears on the display.

7. Press the MENU button to exit the menu.

Uploading data can be done

in any moment, when the instrument is switched on

and needs no choice from the Danhild Menu system !

5.

Use the - and + buttons to select the desired MIDI-channel.

6.

Press the ENTER button.

The display shows:

Swell Msb

7.

If needed, use the - and + buttons to select the

desired Msb setting.

8.

Press the ENTER button. The display shows:

Swell Lsb

.

9.

If needed, use the - and + buttons to select

the desired Lsb setting.

10. Press the ENTER button.

The display shows:

Swell Voice

.

11. Use the - and + buttons to select the desired register setting.

12. Press the ENTER button.

The selected configuration is now stored in memory.

The first of the four parts of the

programmable MIDI code appears on the display.

13. Press the MENU button to return to the main menu.

14. Press the MENU button to exit the menu.

(You can read about MIDI codes on page 27)

Swell Msb

2 0 0 1

Swell Lsb

2 0 0 1

Swell Voice

2 0 0 1

Swell Channel

2 0 0 1

Menu:

MIDI Config

Mem: 1

Vol: 25

Tr: 0/440

Exp: Sw

Menu:

Datadump

Datadump

Press ENTER

Datadump

Sending data...

Do not use the instrument when you see

Sending data...

on the display.

Menu:

Datadump

Mem: 1

Vol: 25

Tr: 0/440

Exp: Sw
