SPECIFICATIONS

OVERVIEW

Technology

Advanced Physical Modelling

Manuals

3

Total Stop Controls

45 Organ + 3 Orchestral

Pedal

10

MAN I

11

MAN II

11

MAN III

13

Alternative Organ Voices

5 or more on each tab

Alternative Orchestral Voices

30 or more on each orchestral tab

Couplers

3

General Memories

1000 (000 - 999)

Memory Slots

3 slots x 1000 each

Total Memories

3000

Piston Sequencer

Two thumb pistons

DIMENSIONS

Height (excluding music desk)

cm 170,5

Height (including music desk)

cm 113,4

Width

cm 126,4

Depth (excluding pedal board)

cm 61,8

Depth (including pedal board)

cm 99,0

Weight

Kg 115 - Lbs 253

CABINET

Laminated Wood

Dark oak, Light oak

ACCESSORIES

Bench

Included

Adjustable Bench

Optional

Orchestra and Midi Sustain

Side Switch on Expression Pedal

DISPLAY

Display Dimensions

128 x 64 dots Graphic with Backlight

Stops Voicing

Available

Divisional Volume

Available

Tremulant

2 independent for each division

Reverb

8 presets

Ensemble Effect

Adjustable

Temperaments

19 Historical + 4 user programmable

Short Octave

Available

Keyboards Inversion

Available

Internal Routing

Programmable for each stop

Internal Equalizer

5 Band Graphic EQ

MIDI Sequencer

Available

File Manager

Load, Save, Backup, Restore

Lock Organ

With Password

MUSIC DESK

Wooden Desk

Included

Adjustable Desk

Optional

MANUALS - KEYBOARDS

Standard Keyboards

Optional

Plastic Black Keyboard Covered with Real Wood

Included

Ivory / Wood Colored Plastic With Wooden Core

Optional

Viscount AWK Keyboards With Wooden Core

Optional

PEDALBOARD

30 note Straight Concave or Flat, Radiating Concave

Available

CONNECTIONS

MIDI In - MIDI Out

Available

Aux In, Aux Out

Available

Headphones Out

Available

USB

A-Type (USB pen) B-Type (Connection to Physis Editor)

EXTERNAL OUTPUTS

Channels

4 programmable (optional: up to 12)

Channel Assign

Voice, General, Sub, Reverb

Equalizer

5 Band Graphic EQ for each channel, EQ for Sub

Routing

Programmable for each stop

Volume

Adjustable for each channel

REVERB SYSTEM

True Stereo Reverb

8 new unique presets

Additional Parameters:

Wet/Dry, Early reflection, Decay time

Left/Right

SOUND AMPLIFICATION

Internal Amplifiers

6 Class-D amplifier 150W per channel

Internal Speakers

10 total | 4 tweeter | 4 mid-range | 2 x 8” woofer

Channel Assignable

Reverb LR | General | Sub

PIPE SETS

Baroque, Romantic, Symphonic + 3 assignable sets

DISPLAY MENU FUNCTIONS

Temperaments

Available

Pipe Set

Available

Pitch

Available

Crescendo Steps

Available

2x Expression Pedals Level

Available

Transposer

Available

Quick Access

Levels (Master, Reverb, Ext Out, ...); Songs
